| Serial number |
Model |
Name |
Specification range |
Rated voltage |
| 1 |
TRVV High Flexibility Cable |
Super Special Flexible Cable with Mixed PVC Insulated and Modified PVC Sheath |
2-24 cores 0.12-0.5MM2; 2-5 cores 0.75-16MM2. |
＜0.5MM2 300/300V ≧0.5MM2 300/500V; |
| 2 |
TRVEP High Flexibility Cable |
Hybrid PVC insulated and PUR sheathed ultra-special high-flexibility shielded cable |
2-24 cores 0.12-0.5MM2; 2-5 cores 0.75-16MM2. |
＜0.5MM2 300/300V ≧0.5MM2 300/500V; |
| 3 |
TRVE High Flexibility Cable Curve |
Hybrid PVC Insulated and PUR Sheathed Super Special High Flexibility Curved Cable |
2-24 cores 0.12-0.5MM2; 2-5 cores 0.75-16MM2. |
＜0.5MM2 300/300V ≧0.5MM2 300/500V; |
| 4 |
TRVESPHigh flexible cable |
Hybrid PVC insulated and PUR sheathed multi-logarithmic ultra-special high-flexibility shielded cable |
2-36 core 0.12-0.5MM2; |
＜0.5MM2 300/300V ; |
| 5 |
TRYEHigh flexible cable |
TPE Insulated and PUR Sheathed Super Special High Flexible Cable |
2-24 cores 0.12-0.5MM2; 2-5 cores 0.75-16MM2. |
＜0.5MM2 300/300V ≧0.5MM2 300/500V; |
| 6 |
TRYEPHigh flexible cable |
TPE insulated and PUR sheathed ultra-special high-flexibility shielded cable |
2-24 cores 0.12-0.5MM2; 2-5 cores 0.75-16MM2. |
＜0.5MM2 300/300V ≧0.5MM2 300/500V; |
| 7 |
TRYESPHigh flexible cable |
TPE Insulated and PUR Sheathed Multi-logarithmic Super Special High Flexible Shielded Cable |
2-36 core 0.12-0.5MM2; |
＜0.5MM2 300/300V |
| Product Code Description |
FRC: Robot Cable, R: Soft, V: Mixed PVC Material, Y: TPE Polymer Insulation Material, E: PUR High Elasticity Material, S: Core Wire to Wind P: Aluminum Foil, Copper Wire Braided Shielding (optional) |
|
-
Suitable for installation in dry or humid room, free continuous reciprocating movement without strong stress release or forced guidance.
Especially in the frequent bending occasions in the industrial environment, such as woodworking machinery, machine tool processing equipment, logistics transportation system, crane occasions.
Mainly used in control measurement and power circuit, and applied in automation industry, assembly line, production line and so on. For example, robot reciprocating motion, robot arm, automobile door, engraving machine, machine tool processing equipment, woodworking machinery, logistics delivery system, crane and metallurgical industry.
-
Conductor: High flexural strength, multi-strand ultra-fine pitch stranded fine-stranded oxygen-free copper wire, meeting the VDE0295 CLASS 6 standards.
Strengthened conductor tension parts: When conductor is stranded, appropriate amount of Kevlar is added in the center to make it precise and smooth.
Insulation: High Mechanical Properties Special Mixed PVC Insulation/TPE Elastic Material (optional)
Colour: <0.5mm, red, yellow, green, blue, black, grey, white, purple, pink, brown, orange
Black digital white number greater than 0.75mm, with yellow-green grounding wire over 3 cores (yellow-green optional)
For logarithmic cables, the color of more than 12 cores can be expressed by adding color discrimination. For logarithmic stranding, the same color + color indication.
Control cable, number of cores (> 12 cores), cores are twisted twice, especially in torsional structure
Core stranding: small pitch regular stranding, with reinforced core in the middle of the core
Reinforcement Core: Kevlar or Nylon Knitting Rope
Filler: Symmetrical filling with nylon rope or cotton rope tension parts.
Shielding: Tin-plated copper mesh braided shielding with high flexural strength, with a density of over 80%.
Isolation layer: non-woven wrapping
Sheath: Special modified PVC sheath or PUR elastic material (optional, customized)
Sheath color: black (similar to RAL9005)
Grey (similar to RAL7001)
Orange (similar to RAL 2003)
-
Rated voltage: <0.5mm2 300/300V; > 0.5mm2 300/500V
Test voltage: <0.5mm2 1500V/5min; > 0.5mm2 2000V/5min
Temperature range: - 35 ~ + 90
(Mobile Installation) When the stroke is less than 10 meters, the bending radius is 6.8 x D.
When the stroke is more than 10 meters, the bending radius is 7.5 x D.
Temperature range: - 50 to + 90.
(Fixed laying) Bending radius: 4 *D
Maximum speed: 10 m/s; 5 m/s
(Overhead/taxiing)
Maximum speed: 60 m/s
The highest temperature can be reached during short circuit: +250 C
Bending life: 30 times per minute, > 20 million times
Flame Retardant Property: Complying with IEC332-1 Standard
Material properties: cold resistance, water hydrolysis and oil resistance, radiation resistance, ozone resistance, weather resistance, acid and alkali resistance
High wear resistance, high mechanical load, excellent flexibility and distortion resistance
-
High softness, bending resistance and torsion resistance design structure to avoid frequent movement and bending of cables and breaking of lower core wires;
Wear resistance: Excellent wear resistance and notch resistance, avoiding cable skin damage due to environment or use;
Waterproof performance: high-quality water-proof special sheath material selection, cable waterproof performance is excellent, hydrolysis resistance, antimicrobial performance is excellent;
Anti-jamming: Aluminum foil/tin-plated copper mesh braided cable shielding layer, cable has excellent anti-electromagnetic interference performance;
-
