Wires and cables for railway locomotives and rolling stock
- Product Model, Production Range
- Product Usage
- Product Structure
- Product Performance
- Product Advantage (Selling Point)
- Product Code Identification
-
Table 1 Type and Name of CableSerial number Model Rated voltage 名 稱 1 WDZ-DCYJ-125 500V、750V、1kV、1.5kV、3kV 銅芯耐熱125℃交聯聚烯烴絕緣無鹵低煙阻燃機車車輛用電纜 2 WDZ-DCYJ/B-125 750V 銅芯耐熱125℃高強度薄壁交聯聚烯烴絕緣無鹵低煙阻燃機車車輛用電纜 3 WDZ-DCYJ/B-150 750V 銅芯耐熱150℃高強度薄壁交聯聚烯烴絕緣無鹵低煙阻燃機車車輛用電纜 2、Cable specifications are shown in Table 2. Serial number Model Rated voltage Specifications mm2 1 WDZ-DCYJ-125 500V 1，1.5，2.5，4 2 WDZ-DCYJ-125 750V，1.5kV，3kV 0.75，1，1.5，2.5，4，6，10，16，25，35，50，70，95，120，150，185，240，300 3 WDZ-DCYJ/B-125 750V 0.5，0.75，1，1.2，1.5，2.0，2.5，4，6 Product Code Description DC = series code - Cables for locomotives and rolling stock (wires); WDZ = product characteristics - halogen-free low smoke flame retardant; YJ = insulating materials - cross-linked polyolefin B = insulation characteristics - high strength thin-walled insulation; 125 = heat-resistant characteristics - heat-resistant 125 degrees C; 150 = heat-resistant characteristics - heat-resistant 150 degrees C -
WDZ series of railway locomotive and rolling stock wires and cables are insulated by low smoke, halogen-free flame retardant cross-linked polyolefin. The products are mainly suitable for power transmission of railway locomotive and rolling stock with rated AC voltage of 3 kV or less. They have excellent cold resistance, oil resistance, ultraviolet resistance, low smoke, halogen-free and high flame retardant properties.
-
Wire: Multi-strand tin-plated copper wire twisted. Chinese style
Isolation layer: wrapped with synthetic mica tape or temperature-resistant flame retardant tape, overlap rate (> 50%)
Insulation Layer: High strength, high temperature resistant cross-linked polyolefin insulation, optional color.
-
The rated voltage U0/U is 500V, 750V, 1KV, 1.5KV and 3KV. The rated DC voltage is 1.5 times the rated AC voltage.Long-term allowable working temperature of wire and cable: 125 product is 125 C; 150 product is 150 C.Minimum ambient temperature of cables: non-B-40 C; B-60 C.Permissible bending radius for laying wires and cables:Cable outer diameter (D) should be no less than 3-D when 20 mm or less.When the outer diameter (D) of the cable is more than 20 mm, it should be no less than 5 D.WDZ-DCYJ-125 cable can be used in oil contaminated environment; WDZ-DCYJ/B-125, WDZ-DCYJ/B-150 cable can be used in harsh environment with various kinds of grease contamination and non-high concentration acid-base contamination.Insulation Resistance at 20 C: The rated voltage of WDZ-DCYJ-125, WDZ-DCYJ/B-125 and WDZ-DCYJ/B-150 cables should be no less than 1010_.km.
AC test voltage of finished cable:
Rated voltage
500V
750V，1kV
1.5kV
3kV
AC Voltage Test
2kV/15min
3.5kV/15min
6kV/15min
12kV/15min
Halogen-free characteristics of cables:The total amount of halogen gas is 5 mg/g.PH value (> 4.3);Transmittance: > 80%The conductivity is less than 10 uS/mm.Flame Retardant Performance of Cable: Through GB/T 18380 Single Vertical Combustion Test。
-
It has excellent cold resistance, oil resistance, ultraviolet resistance, low smoke, halogen-free and high flame retardant properties.
-
